In this post, we will learn on how to create a maven web application project

Tools used

  • Spring Tool Suite (version: 3.9.4.RELEASE)
  • Maven (version: 3.5.2)
  • Java (version: 1.8)
  • Tomcat (version: 9.0.2)

Steps

  1. Create new Maven project
  2. Configure Tomcat
  3. Create src/main/java and src/test/java folders, if there aren’t any
  4. Run the application

Screen shots

Step 1 – Create Maven web application project using either Eclipse IDE or STS

  1. Click New->Maven Project
    1. Select default location
    2. Select “maven-archtype-webapp”.
    3. Enter Group Id, Artifact Id, package details and hit finish

Below is the project structure after hitting finish

Eclipse

Note: If you look in the problems view, the error is “The superclass “javax.servlet.http.HttpServlet” was not found on the Java Build Path. This error indicates that http-servlet is not available in the project class path, once we add target-runtime to the project , http-servlet will be available in the project class-path.

Spring

Errors will be resolved after configuring run time server such as Tomcat server

Step 2 – To configure Tomcat server:

  1. Right click on project and select “Properties”.
  2. Select “Targeted Runtimes” on left hand side.
  3. Select “Apache Tomcat v9.0”.
  4. Click apply and close

Step 3 – To create src/main/java and src/main/test folders,

  1. Right click on project structure, select “Properties”,
  2. Select “Java Build Path” on left hand side
  3. On right hand side, select “Order and Export” tab
    1. select “Maven Dependencies” and “JRE System Library”
    2. select apply and close

Note: If you still see errors, right click on project and do Maven -> update projectAcronis true image 2020 universal restore.

Step 4 – Run the application

Spring Sts Download

  1. Right click on project, select Run As and Run on Server
  2. Select Tomcat server in the window
  3. Select Finish
  4. Type http://localhost:8080/SpringMVC/ in your favorite web browser to see “Hello World” message

Project Structure

Spring Sts Eclipse

Final maven project structure looks like below
